Turbodrive 224 D.D.
Compact and reliable, the Turbodrive 224 D.D. is built for smaller craft that demand agility without compromising on performance. Its lightweight design and efficient axial flow impeller deliver smooth, responsive handling in tight waterways. Odyssey Marine's technicians are specially trained to service and maintain this unit, keeping it running at its best.
| Spec | Value |
|---|---|
| Impeller | 4 blades, single stage, axial flow (matched to 110 mHP @ 3,200 rpm engines, or same cubic power curve) |
| Impeller diameter | 224 mm at the inlet |
| Stator | 5 blades |
| Gearbox | None — impeller directly driven by engine |
| Input flange | Up to 170 mm diameter drive shaft flange |
| Transom angle | 93° |
| Water pick-up (engine cooling) | 1" (33.3 mm) GAS |
| Unit dry weight | 61.7 kg (all components and hydraulics) |
| Electric oil pump (separate) | 11 kg |
| Entrained water volume | 30 litres |
| Water intake protection | Fixed debris screen grid |
| Max power input | 147 kW (200 mHP) |
